Gas Heat Pump ( GHP ）Cooling and Heating Air Conditioner

Gas Heat Pump ( GHP )Cooling and Heating Air Conditioner

What is a gas heat pump air conditioner?
The gas heat pump air conditioner is an air conditioning unit that drives the compressor through a gas engine and circulates the gas heat pump for cooling or heating.

The difference between the gas heat pump air unit and the air source heat pump air conditioner is: the gas V heat pump air conditioner uses the TN city gas as the energy source: the air source heat pump air conditioner is driven by the built-in motor of the compressor, driven by the gas engine, and uses the gas as the energy source: the work uses electricity as the energy source .Self-developed GHP special gas engine.

Remark:

1. Refrigeration: The outdoor temperature is 35°C, and the outlet water temperature is 7°C. When the outlet water temperature is lower than 5°C during operation, antifreeze must be used as the refrigerant water.

2. The amount of heat recovery under refrigeration conditions: the outlet water temperature is 45°C. (Please note that this function is required when ordering)

3. Heating (nominal): outdoor temperature 7/6°C, outlet water temperature 45°C; heating (low temperature): outdoor temperature 2/1°C, outlet water temperature 45°C.

4. The type of gas is natural gas, and the pressure is low pressure. (Maximum pressure: 2.5kpa; Standard pressure: 2.0kpa; Minimum pressure 1.0kpa)

5. Actual gas consumption (Nm3/h) = gas consumption (kW) X3.6/35.4 (MJ/Nm3)

6. If the product is updated, the data is subject to change without prior notice.
